Product Overview:

Hygienic pipe fittings are a type of pipe connection components designed to meet the fluid transportation requirements of industries with strict hygiene standards, such as food, beverages, pharmaceuticals, biomedicine, dairy products, cosmetics, etc.

The core features include compliance with stringent hygiene standards, easy cleaning, no dead corners, corrosion resistance, and the ability to prevent fluid stagnation and microbial growth. They are a key component of clean fluid systems.

Product Specifications: DN15 - 150mm and 1/2" - 6"

Product Material: SS304/316L Connection method: welding / clamp / thread connection

Product Overview:

The sanitary ball valve is a type of valve where the opening and closing element is a spherical body. The valve is opened and closed by the rotation of the spherical body around the valve stem axis, thereby controlling the flow of fluid. When the spherical body rotates to the position where it is in contact with the valve seat, the passage is closed.

when the spherical body rotates 90° to the position where it is separated from the valve seat, the passage is opened, allowing the fluid to pass through.

Product Specifications: DN15 - 150mm and 1/2" - 6"

Product Material: SS304/316L Connection method: Various connection methods such as quick assembly, welding, threading, and flange are available.

Product Overview:

The sanitary butterfly valve is a type of pipeline on-off control valve specifically designed for industries with strict hygiene requirements such as food, pharmaceuticals, dairy products, and cosmetics. It achieves opening and closing through the rotation of the butterfly plate, featuring a compact structure, convenient operation, and easy cleaning. It can be adapted to CIP (Continuous In-Line Cleaning) and SIP (Continuous In-Line Sterilization) processes.

Product specifications: DN15 - 200mm and 1/2" - 8"

Product material: SS304/316L

Connection method: welding / quick assembly / thread / flange / vacuum

Product Overview:

The sanitary diaphragm valve is a device used for controlling water, gas, oil products, and corrosive media. It is applied in industries such as chemical engineering, petroleum, metallurgy, plumbing, food, pharmaceuticals, biotechnology, dairy products, beverages, cosmetics, and electronics. This valve is operated by a driving device (manual, pneumatic, or electric), and the driving device has three standard types: normally closed type, normally open type, and pneumatic- pneumatic type. It features a simple structure, easy disassembly and installation, simple operation, low fluid resistance, no dead corners in design, and is easy to clean. It can also achieve online sterilization, ensuring safety of use and meeting hygiene requirements.

Product specifications: DN15 - 100mm and 1/2" - 4"

Product material: SS304/316L

Connection method: Clamp/ welding/ thread/ flange, etc.

Product Overview:

The sanitary level gauge is a device used to observe the flow of liquids, gases, vapors, etc. It is widely applied in industries with extremely high hygiene requirements such as food and pharmaceuticals.

Product size range: DN15 - 150mm and 1/2" - 6"

Product material: SS304/316L

Connection method: Flange / Thread / Butt Weld / Clamp, etc.

Product Overview:

The sanitary manhole is an inspection, observation and cleaning passage installed on the top or side wall of storage tanks, reaction vessels, fermentation tanks, and blending tanks in industries such as food, pharmaceuticals, dairy products, beverages, and bioengineering. It adopts a sanitary structure design without dead corners, easy to clean, and corrosion-resistant, and is a standard accessory necessary for clean tank bodies.

Nominal diameter: DN10mm to 600mm and 1/2' to 24'

Product material: SS304/316L

Types: Atmospheric pressure type, pressure type with sight glass, handwheel type, rectangular, elliptical, elliptical with sight glass, handhole, square, etc.; Non-standard manholes can be processed according to customer's drawings or samples.

Product Overview:

Sanitary Flange: Also known as union, union fitting, sanitary flange joint, sanitary threaded joint, or sanitary thread joint, it is mainly composed of a nut, a head, a flat connection, and a sealing element. It primarily serves as a threaded connection in fluid pipelines and is specifically used in industries such as dairy products, food, pharmaceuticals, beer, beverages, fine chemicals, and bioengineering.

Sanitary grade clamp: Used in conjunction with quick-connect clamps and sealing rings, it can be quickly locked without welding, providing efficient and convenient installation and disassembly. It offers reliable sealing with no leakage. It is the core component for quick connection in clean pipelines, and is compatible with various quick-connect valves and pipe fittings for rapid connection.

Product specifications: DN15 - DN150mm and 1/2" - 6"

Product material: SS304/316L

Product Overview:

Matching valves refer to devices that are specifically designed to match certain equipment, piping systems, or process procedures, and are used to control parameters such as flow, pressure, and temperature of fluids (such as liquids, gases, etc.). The products are widely used in fields such as food, pharmaceuticals, dairy products, beer, beverages, and fine chemicals.

Product specifications: DN15 - DN150mm and 1/2" - 6"

Product material: SS304/316L

Connection method: Clamp/焊接/Welding/Threaded connection, etc.
